Important notes before you order
- Does not fit power wagon models due to unique suspension and electronic sway bar disconnect.
- Due to variances in motor weight this kit only fits diesel models.
- Does not fit models equipped with a manual transfer case.
TRU specialist notes
From the Trucks R Us fitment and install team, beyond the manufacturer's information.
- Plan for a professional wheel alignment after installing any lift or leveling kit.
- Going to bigger tires as well? Speedometer recalibration may be needed, and some tire and wheel combinations need trimming. Check the recommended wheels and tires, or ask us before you order.
Specifications
| Brand | Rough Country |
|---|---|
| Part number | 35230 |
| UPC / GTIN | 8402699741510 |
| Front Lift Height | 5" |
| Rear | Rear Lift Spacers Track Bar Bracket Sway-Bar Links Bump Stop Brackets Hardware |
| Install time | 7-10 hours |
| Weight (lbs) | 294.35lbs |
| Country of Origin | USA |
| Warranty | Manufacturer’s Warranty Statement |
What's in the box
| Qty | Part | Description |
|---|---|---|
| — | — | Front: Lifted Coil Springs Radius Arms Track Bar Bracket Bump Stops Sway-Bar Brackets Driveshaft Pitman Arm Hardware |
| — | — | Rear: Rear Lift Spacers Track Bar Bracket Sway-Bar Links Bump Stop Brackets Hardware |
Features
- Increased ground clearance: tackle tough terrain with added lift height that delivers superior off-road capability and obstacle-clearing confidence.
- Leveled, aggressive stance: eliminates factory rake by leveling the front with the rear, giving your ride a clean, commanding profile.
- Precision axle positioning: front track bar drop bracket maintains proper axle alignment for enhanced handling and minimized wear.
- Heavy-duty radius arms: built for strength with factory-style geometry and premium rubber bushings that reduce vibration and boost ride quality.
- Improved steering response: includes a drop pitman arm to correct steering angles and preserve smooth, predictable control after lifting.
- Consistent coil spring performance: linear-rate front and rear coil springs deliver balanced flex, ride comfort, and load handling.
- Premium n3 shock absorbers: application-valved n3 series shocks provide reliable damping and balanced performance on- and off-road.
- Front driveshaft included: comes complete with a front driveshaft upgrade to handle the added articulation and drivetrain angles of the lift.
- 37-inch tire clearance: designed to easily fit aggressive 37" tires, giving your build a bold stance and improved trail capability.
Fitment
| Years | Vehicle |
|---|---|
| 2025-2026 | 4WD Ram 3500 |
Use the fit check above with your truck selected, or ask a specialist if your trim isn't listed.
Recommended wheels & tires
27 tire and wheel combinations from Rough Country. Pick a wheel size to narrow the list.
| Tire | Wheel | Bolt Pattern | Offset | Note |
|---|---|---|---|---|
| 37x12.50R17 | 17x8.5 | 8x6.5/8x165.1 | +0 | – |
| 37x12.50R17 | 17x8.5 | 8x6.5/8x165.1 | +1 | – |
| 37x12.50R17 | 17x9 | 8x6.5/8x165.1 | +0 | – |
| 37x12.50R17 | 17x9 | 8x6.5/8x165.1 | +1 | – |
| 37x12.50R20 | 20x9 | 8x6.5/8x165.1 | +0 | – |
| 35x12.50R20 | 20x9 | 8x6.5/8x165.1 | +0 | – |
| 37x12.50R20 | 20x9 | 8x6.5/8x165.1 | +1 | – |
| 35x12.50R20 | 20x9 | 8x6.5/8x165.1 | +1 | – |
| 37x12.50R20 | 20x10 | 8x6.5/8x165.1 | -25 | Minor Trimming |
| 35x12.50R20 | 20x10 | 8x6.5/8x165.1 | -25 | – |
| 37x12.50R20 | 20x10 | 8x6.5/8x165.1 | -24 | Minor Trimming |
| 35x12.50R20 | 20x10 | 8x6.5/8x165.1 | -24 | – |
| 37x12.50R20 | 20x10 | 8x6.5/8x165.1 | -19 | Minor Trimming |
| 35x12.50R20 | 20x10 | 8x6.5/8x165.1 | -19 | – |
| 37x12.50R20 | 20x10 | 8x6.5/8x165.1 | -18 | Minor Trimming |
| 35x12.50R20 | 20x10 | 8x6.5/8x165.1 | -18 | – |
| 37x12.50R20 | 20x12 | 8x6.5/8x165.1 | -44 | – |
| 35x12.50R20 | 20x12 | 8x6.5/8x165.1 | -44 | Trimming Required |
| 37x12.50R22 | 22x10 | 8x6.5/8x165.1 | -25 | Minor Trimming |
| 35x12.50R22 | 22x10 | 8x6.5/8x165.1 | -25 | – |
| 37x12.50R22 | 22x10 | 8x6.5/8x165.1 | -24 | Minor Trimming |
| 35x12.50R22 | 22x10 | 8x6.5/8x165.1 | -24 | – |
| 37x12.50R22 | 22x10 | 8x6.5/8x165.1 | -19 | Minor Trimming |
| 35x12.50R22 | 22x10 | 8x6.5/8x165.1 | -19 | – |
| 37x12.50R22 | 22x10 | 8x6.5/8x165.1 | -18 | Minor Trimming |
| 35x12.50R22 | 22x10 | 8x6.5/8x165.1 | -18 | – |
| 35x12.50R22 | 22x12 | 8x6.5/8x165.1 | -44 | Trimming Required |
Installation
- Estimated install time7-10 hours
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
Commanding Lift. Confident Performance: Transform your RAM 3500 with Rough Country's 5-Inch Lift Kit, engineered for bold looks and off-road domination. Featuring linear coil springs, a heavy-duty front driveshaft, and application-valved N3 shock absorbers, this kit delivers increased ground clearance, leveled stance, and trail-tested performance, all while maintaining a smooth, factory-like ride. Precision Suspension Engineering: Maintaining proper suspension geometry is critical for both on- and off-road control. This kit includes a drop pitman arm to correct steering angles and a track bar drop bracket to keep your front axle perfectly centered, ensuring stable, predictable handling at every turn. Heavy-Duty Radius Arms: Custom radius arms bolt directly to factory mounts and retain factory-like angles. Outfitted with premium rubber bushings, they minimize vibration and noise while maximizing ride comfort and suspension travel. Linear Coil Springs for Consistency: Front and rear linear-rate coil springs offer a reliable, controlled ride with balanced articulation and load handling, perfect for daily driving, towing, or backcountry exploring. Upgraded Front Driveshaft Included: This kit comes complete with a high-clearance front driveshaft designed to accommodate added articulation and drivetrain angles, no need for costly aftermarket upgrades. Includes N3 Series Shocks: Rough Country's N3 shocks are specifically valved for your RAM 3500, delivering balanced performance both on the highway and in rugged off-road environments. Clears 37-Inch Tires with Ease: Run aggressive 37-inch tires with confidence. This kit gives your RAM the clearance it needs for true off-road capability and a head-turning stance.
Questions
Will this fit my truck?
Select your truck at the top of the page and the fit check will confirm it. If your exact trim is not listed, call 866-235-4715 or live chat and a fitment specialist will check it before you order.
Do you help with installation?
Yes. Our technical team helps you or your shop with installation and troubleshooting after delivery, on top of the manufacturer’s support.
What if the part has a problem?
We work the warranty claim with the manufacturer on your behalf, within the manufacturer’s warranty policy.
Can I return it?
Most items can be returned within 30 days. See our return policy for details.
Do I need an alignment after installing?
Yes. Any lift or leveling kit changes suspension geometry, so get a professional alignment after installation.
