Rough Country 110700 4 Inch Lift Kit · AT4X GMC Sierra 1500 4WD (2022-2024)
- Front lift 4"
- Install 8-10 hours
Questions about fitment? Live chat or call 866-235-4715
Couldn't load pickup availability
- Free shippingMost orders $500+
- 30-day returnsSee policy
- Warranty supportWe work with the maker
Questions about fitment?
Talk to a TRU specialist
We’ll help you verify fitment before you buy.
Veteran-owned · Austin, Texas · Mon–Fri 9:30a–11:00a & 1:00p–5:30p CT
Important notes before you order
- Requires cutting to complete installation.
- Only fit at4x models as it is equipped with a 2-inch factory lift and multimatic dssv dampers .
- Due to variances in the front skid plate this kit does not fit at4x aev models.
- Tire & wheel details does not fit factory wheels.
- 20-inch or larger aftermarket wheels are required.
- Wheels must feature 4.
- 5in backspacing to fit.
- Please test fit wheels prior to installation.
- Some aftermarket wheels may require 0.
- 25" wheel spacer #1065 .
TRU specialist notes
From the Trucks R Us fitment and install team, beyond the manufacturer's information.
- Plan for a professional wheel alignment after installing any lift or leveling kit.
- Going to bigger tires as well? Speedometer recalibration may be needed, and some tire and wheel combinations need trimming. Check the recommended wheels and tires, or ask us before you order.
Specifications
| Brand | Rough Country |
|---|---|
| Part number | 110700 |
| UPC / GTIN | 8402699719210 |
| Front Lift Height | 4" |
| Install time | 8-10 hours |
| Weight (lbs) | 225.00lbs |
| Country of Origin | USA |
| Warranty | Manufacturer’s Warranty Statement |
What's in the box
| Qty | Part | Description |
|---|---|---|
| — | — | Front: Lifted Knuckles Upper Strut Spacers Front Crossmember Rear Crossmember CV Spacers Differential Drop Brackets Differential Skid Plate Sway-Bar Drop Brackets Hardware |
| — | — | Rear: Fabricated Lift Blocks Brake Line Brackets Shock Relocation Brackets U-Bolts Hardware |
Features
- Front-to-rear leveling: lifts and levels your vehicle for a balanced, aggressive stance.
- High clearance design: engineered crossmember ensures optimal suspension geometry and improved ground clearance.
- Extreme durability: includes heavy-duty cast knuckles built to withstand the harshest terrain.
- Maintains factory width: retains oem track width for reliable handling and stability.
- Hassle-free installation: no strut disassembly required, bolt-on design simplifies the install process.
- No cutting needed: no differential trimming required, preserving factory components.
- Precision engineering: crafted from laser-cut materials using advanced cad for perfect fitment.
- Stronger than cast: fabricated rear blocks deliver superior strength and extended durability.
- Oe shock compatibility: includes rear shock brackets designed specifically for oe multimatic shocks.
Fitment
| Years | Vehicle |
|---|---|
| 2022-2024 | 4WD GMC Sierra 1500 |
Use the fit check above with your truck selected, or ask a specialist if your trim isn't listed.
Recommended wheels & tires
- TireWheelBolt PatternOffsetNote35x12.50R2020x96x5.5-12-295/65R2020x96x5.5-12-295/60R2020x96x5.5-12-35x12.50R2020x96x5.5-60.25 Spacer295/65R2020x96x5.5-60.25 Spacer35x12.50R2020x106x5.5-25Minor Trimming295/65R2020x106x5.5-25-295/60R2020x106x5.5-25-35x12.50R2020x106x5.5-24Minor Trimming295/65R2020x106x5.5-24-295/60R2020x106x5.5-24-35x12.50R2020x106x5.5-19Minor Trimming295/65R2020x106x5.5-19-295/60R2020x106x5.5-19-35x12.50R2020x106x5.5-18Minor Trimming295/65R2020x106x5.5-18-295/60R2020x106x5.5-18-35x12.50R2020x126x5.5-44Trimming Required35x12.50R2222x106x5.5-25Minor Trimming35x12.50R2222x106x5.5-24Minor Trimming35x12.50R2222x106x5.5-19Minor Trimming35x12.50R2222x106x5.5-18Minor Trimming35x12.50R2222x126x5.5-44Trimming Required
Installation
- Estimated install time8-10 hours
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
Command the Terrain: GMC's fourth-generation Sierra 1500 AT4X already turns heads with bold styling and rugged capability, but Rough Country's 4-Inch Suspension Lift Kit takes it even further. Achieve the aggressive stance you crave with a leveled front-to-rear ride and enough clearance to run 35-inch tires without additional modifications. Precision Engineering Meets Rugged Performance: Designed to maintain optimal suspension geometry, this kit features high-clearance crossmembers and heavy-duty cast knuckles for extreme durability in the toughest environments. Upper strut spacers offer uncompromised strength and rigidity while preserving your factory ride quality. Rear fabricated lift blocks and shock relocation brackets ensure your OE Multimatic shocks stay perfectly aligned, delivering consistent performance and extended component life. Factory Fit, No Compromises: No strut disassembly or differential trimming required, this lift kit is engineered for a straightforward installation while retaining your factory track width. All components are crafted using 100% precision laser-cut materials and advanced CAD processes for a perfect fit every time. DIY-Friendly Installation: Estimated installation time is 8-10 hours. This kit is ideal for skilled DIYers or professional installers looking for a smooth and efficient install process. Limited Lifetime Replacement Warranty: Rough Country's 4" Suspension Lift Kit is backed with a limited lifetime replacement warranty towards manufacturer defects. As such, the product is protected from structural and workmanship damage after the date of purchase. With our industry-leading warranty give yourself peace of mind when using Rough Country's Suspension products!
Questions
Will this fit my truck?
Select your truck at the top of the page and the fit check will confirm it. If your exact trim is not listed, call 866-235-4715 or live chat and a fitment specialist will check it before you order.
Do you help with installation?
Yes. Our technical team helps you or your shop with installation and troubleshooting after delivery, on top of the manufacturer’s support.
What if the part has a problem?
We work the warranty claim with the manufacturer on your behalf, within the manufacturer’s warranty policy.
Can I return it?
Most items can be returned within 30 days. See our return policy for details.
Do I need an alignment after installing?
Yes. Any lift or leveling kit changes suspension geometry, so get a professional alignment after installation.
No reviews for this part yet. Trucks R Us is rated on Trustpilot, Google and the BBB.
About Rough Country
Rough Country is a leading manufacturer and distributor of off-road accessories and suspension systems. Built on a foundation of American values and rooted in Tennessee, we use our expertise of trucks, Jeeps, and UTVs to help people drive their passions... Shop all Rough Country
