ICON 2005-2016 Ford F-250/F-350 Super Duty 4WD Diesel, 2.5" Lift, Stage 3 Suspension System

Name: ICON 2005-2016 Ford F-250/F-350 Super Duty 4WD Diesel, 2.5" Lift, Stage 3 Suspension System
Brand: ICON Vehicle Dynamics
SKU: K62502
Price: 3032.09 USD
Availability: InStock

PART #

$3,032.09

SALE CALL OR CHAT TO ORDER

Shipping calculated at checkout.

Product variants

Quantity

Inventory: Low (Live-Chat or Call For Stock)

View full details

Important: Always read the entire product description, including Features, Important Notes, Specifications, and Fitment data, before making a purchase. Components contained in images and descriptions may change based upon your selections.

For F-250 applications, a 4" block can be used in place of your factory 2" block, in turn leveling the truck from front to rear, allowing use of ICON Rear Shocks.

Features

ICON engineered dual rate coil springs with match tuned performance shocks
Application Specific Alignment Cams ensure proper Caster alignment
Corrosion resistant one-piece impact extruded aluminum shock bodies with 7/8" shafts
Increased wheel travel and ride quality over stock with no change in towing capacity
Less body-roll than stock
Lifetime guarantee that coil springs won’t sag
No drive shaft modifications required
100% Bolt-on system - no drilling cutting or welding necessary for install

Oem wheels & tires fitment: not compatible with all available oe wheel/tire combinations.
Aftermarket wheels with lower offset/less backspace recommended.
; tech note: 2005-2016 f-250s require 4” rear blocks with 15” u-bolt kit to sit level with 2.
5” lifted front.
Icon block kit part # 194275 and u-bolt kit part # 37003 (2005-2010 models) or part # 67003 (2011-2016 models) are recommended.
; tech note: not compatible with f-350 cab & chassis models; tech note: icon track bar bracket part # 64039 is also recommended to correct bump steer geometry on 2008-2016 models; tech note: included rear shocks are compatible with 0-3" of rear lift over stock; recommended aftermarket wheels: icon alloys - 17x8.
5" w/ 5.
00” backspace / 6mm offset; recommended aftermarket wheels: icon alloys - 18x9" w/ 5.
25” backspace / 6mm offset; recommended aftermarket wheels: icon alloys - 20x9" w/ 5.
25” backspace / 6mm offset; recommended aftermarket tires: 35" x 12.
50" (larger tires may fit but fender trimming and modifications will be required.
); application note #6: springs are rated for diesel engines only; application note #30: an adjustable track bar may be needed to realign the axle from left to right, or to add additional strength; application note #55: shocks are fully serviceable.
Coilover heights indicated are for a stock equipped vehicle; tech note: compatible with 4wd models only

Quick SpecsOverview:

Spring Material: Steel
Bushings Included: Yes
Mounting Hardware Included: Yes
Spring Color: Black
Shocks Included: Yes
Grade Type: Performance
Maximum Lift: 2.5 IN
Coils Quantity Front: 2
AAP_UDA_12: EA
AAP_UDA_22: 1
AAP_UDA_4: 55
Add-On Part: 64039 - 08-25 FSD TRACK BAR BUMP STEER BRACKET KIT
California Prop 65 Warning: Yes
California Proposition 65: WARNING: This product contains chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Dual Rate Coil Springs: Yes
OEM Wheels &
Tires Fitment: Yes
Recommended Aftermarket Tires: 35" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5” Backspace / 6mm Offset
Title: ICON 2005-2016 Ford F-250/F-350 Super Duty 4WD Diesel 2.5" Lift Stage 3 Suspension System

Additional Specifications:

Country of Origin: US
Warranty: See Rep
Weight (lbs): 112.0
Vehicle Specific Fitment: Y

Instructions

I37705P_REVB.pdf
