Important notes before you order
- CAUTION! Upon receipt of wheels, open one box and conduct a test-fit prior to opening remaining boxes. Do not mount tires until wheel fitment is verified. Once tires are mounted or wheels are otherwise used, damaged, or remaining packaging is opened, wheels are non-returnable.
TRU specialist notes
From the Trucks R Us fitment and install team, beyond the manufacturer's information.
- Confirm bolt pattern, center bore and offset for your exact truck. Some aftermarket wheels need hub-centric rings or different lug nuts. Ask us and we will check your setup.
Specifications
| Brand | Fuel 1PC |
|---|---|
| Part number | D57420901750 |
| UPC / GTIN | 885463849119 |
| Part Number | D57420901750 |
| Finish | Gloss Black Milled |
| Size | 20x9 |
| Bolt Pattern | 8x170 |
| Offset | 1mm |
| Backspacing | 5.04" |
| Center Bore | 125.1mm |
| Load Rating | 3500 lbs |
| Wheel Weight | 44 lbs |
| Lip Depth | 2.14" |
| Construction | Cast Aluminum |
| Cap Part No. | 1002-53GB |
| TPMS Compatible | Yes |
| Part Number | D57420901757 |
| Finish | Gloss Black Milled |
| Size | 20x9 |
| Bolt Pattern | 8x170 |
| Offset | 20mm |
| Backspacing | 5.79" |
| Center Bore | 125.1mm |
| Load Rating | 3500 lbs |
| Wheel Weight | 44 lbs |
| Lip Depth | 2.14" |
| Construction | Cast Aluminum |
| Cap Part No. | 1002-53GB |
| TPMS Compatible | Yes |
| Part Number | D57420001747 |
| Finish | Gloss Black Milled |
| Size | 20x10 |
| Bolt Pattern | 8x170 |
| Offset | -18mm |
| Backspacing | 4.79" |
| Center Bore | 125.1mm |
| Load Rating | 3700 lbs |
| Wheel Weight | 44 lbs |
| Lip Depth | 3.93" |
| Construction | Cast Aluminum |
| Cap Part No. | 1001-79GB |
| TPMS Compatible | Yes |
| Part Number | D57420201747 |
| Finish | Gloss Black Milled |
| Size | 20x12 |
| Bolt Pattern | 8x170 |
| Offset | -44mm |
| Backspacing | 4.77" |
| Center Bore | 125.1mm |
| Load Rating | 3500 lbs |
| Wheel Weight | 46 lbs |
| Lip Depth | 4.49" |
| Construction | Cast Aluminum |
| Cap Part No. | 1002-53GB |
| TPMS Compatible | Yes |
Features
- Cast Aluminum
- TPMS Compatible
- Structural Warranty: Lifetime
- Finish Warranty: One Year
Overview
The Fuel Off-Road Cleaver features bold styling and rugged durability for off-road enthusiasts. Its unique split-spoke pattern and aggressive design make it a standout choice for trucks that demand both performance and style. Available in 5, 6, and 8-lug bolt patterns, the Cleaver fits everything from Jeep Wranglers and Toyota Tacomas to ½-ton trucks like the Ford F-150, RAM 1500, and Silverado 1500. It’s also compatible with ¾-ton and 1-ton trucks such as the RAM 2500 and 3500, Ford F-250 and F-350, and Silverado 2500 and 3500. With sizes ranging from 17" to 24" and offsets from -44mm to +20mm, the Cleaver is built to handle tough terrains while enhancing your off-road build’s appearance.
