Fuel 1PC
Fuel 1PC TRITON DRW 20X8.25 8X6.5 -240 NBL (R)
Fuel 1PC TRITON DRW 20X8.25 8X6.5 -240 NBL (R)
PART #
- Diameter 20"
- Width 8.25"
- Bolt pattern 8X6.5
- Offset -240 mm
- Finish BLACK
Couldn't load pickup availability
- Free shippingmost orders $500+
- 30-day returnssee policy
- Warranty helpwe work claims for you
Important notes before you order
- CAUTION! Upon receipt of wheels, open one box and conduct a test-fit prior to opening remaining boxes. Do not mount tires until wheel fitment is verified. Once tires are mounted or wheels are otherwise used, damaged, or remaining packaging is opened, wheels are non-returnable.
TRU specialist notes
From the Trucks R Us fitment and install team, beyond the manufacturer's information.
- Confirm bolt pattern, center bore and offset for your exact truck. Some aftermarket wheels need hub-centric rings or different lug nuts. Ask us and we will check your setup.
Specifications
| Brand | Fuel 1PC |
|---|---|
| Part number | D58120828D35 |
| UPC / GTIN | 885463851112 |
| Barrel Configuration | R |
| Cap Part No. | 1003-28GB |
| TPMS Compatible | Yes |
| Wheel Weight | 49 |
| Shipping Weight | 55 |
| Style | D581 TRITON |
| Country of Origin | CN |
| Warranty (finish) | ONE YEAR |
| Warranty (structural) | LIFETIME |
| Construction Type | Cast Aluminum |
| Diameter (in) | 20 |
| Width (in) | 8.25 |
| Lug Count | 8 |
| Bolt Pattern (metric) | 8X165.1 |
| Bolt Pattern (standard) | 8X6.5 |
| Offset (mm) | -240 |
| Backspacing (in) | -4.82 |
| Centerbore | 121.5 |
| Load Rating (metric) | 1133 |
| Load Rating (standard) | 2500 |
| Finish (full name) | GLOSS BLACK MILLED |
| Finish (short name) | BLACK |
California Proposition 65 warning applies to this product. www.P65Warnings.ca.gov
Overview
- Diameter (in): 20.0
- Width (in): 8.25
- Lug Count: 8.0
- Bolt Pattern (metric): 8X165.1
- Bolt Pattern (standard): 8X6.5
- Offset (mm): -240.0
- Backspacing (in): -4.82
- Centerbore: 121.5
- Load Rating (metric): 1133.0
- Load Rating (standard): 2500.0
- Finish (full name): GLOSS BLACK MILLED
- Finish (short name): BLACK
Questions
Will this fit my truck?
Select your truck at the top of the page and the fit check will confirm it. If your exact trim is not listed, call 866-235-4715 or live chat and a fitment specialist will check it before you order.
Do you help with installation?
Yes. Our technical team helps you or your shop with installation and troubleshooting after delivery, on top of the manufacturer’s support.
What if the part has a problem?
We work the warranty claim with the manufacturer on your behalf, within the manufacturer’s warranty policy.
Can I return it?
Most items can be returned within 30 days. See our return policy for details.
