FOX Offroad Shocks

FACTORY RACE SERIES 2.0 ATS STABILIZER

Name: FACTORY RACE SERIES 2.0 ATS STABILIZER
Brand: FOX Offroad Shocks
SKU: 983-02-144
Price: 516.35 USD
Availability: InStock

FACTORY RACE SERIES 2.0 ATS STABILIZER

PART #

$516.35

SALE Backordered

Shipping calculated at checkout.

Product variants

Quantity

Inventory: In Stock

View full details

Important: Always read the entire product description, including Important Notes and Fitment information, before making a purchase. Components contained in images and descriptions may change based upon your selections.

Developed from our off-road race shocks FOX Factory Race Series combines race-proven technology with new cutting-edge features to provide enhanced ride-quality and winning damping performance you can bolt onto your truck or SUV.

Features

Adjustable Through Shaft Stabilizer
Performance Tuned For Vehicle Specific Application
Aluminum Body Dissipates Heat Faster Than Steel
Eliminates fluid displacement delivering neutral and consistent damping of unwanted steering feedback
External Reservoir With Compression Adjuster
Black Anodized CNC Machined Aluminum Components

Uncompromised performance through fox’s patented internal bypass technology delivers the feel of near-endless suspension travel.
Exclusive internal bypass technology allows oil to flow around the piston at some points of the stroke – while creating humongous pressure at other points – supporting the vehicle like no other product can.
Floating through terrain is accomplished with fox’s ride zone – combining a race-developed shock piston, internal bypass and dual speed compression adjustment – allowing fine tuning for weight, terrain and speed.
Dominate any terrain with the brute strength of 3- and 2.
5-inch aluminum bodies, cactus cooler reservoirs and 7/8” shafts with redundant seals, all proven in the harshest of environments under the toughest of conditions.

Quick SpecsOverview:

Body Diameter (in): 2
Body Material: Aluminum
Bottom Mount: Eyelet
Compressed Length (in): 16.67 IN
Extended Length (in): 24.78 IN
Fox Catalog: TRUCK
Label Name: 08-16 Ford Superduty ATS Stabilizer 8.1" Trav 24.75" Ext Through-Shaft 1-1/8" Clamp
Prop 65 - Long Label: ! WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Prop 65 Y/N: Y
Reservoir Type: Piggyback
Series: Factory Race
Tie Rod Clamp: 1-1/8"
Title: FACTORY RACE SERIES 2.0 ATS STABILIZER
Top Mount: Tie Rod Clamp
Top Mount (p/n): 026-01-100-1
Travel (in): 8.11 IN
Type: Stabilizer

Additional Specifications:

Country of Origin: US
Warranty: 12 Months
Weight (lbs): 6.6
Vehicle Specific Fitment: Y

Instructions

605-01-124_REV-B.pdf

Fitment

: N/A
