Bilstein 24-359832 B8 5100 (Ride Height Adjustable) - Suspension Shock Absorber
Questions about fitment? Live chat or call 866-235-4715
Couldn't load pickup availability
- Free shippingMost orders $500+
- 30-day returnsSee policy
- Warranty supportWe work with the maker
Questions about fitment?
Talk to a TRU specialist
We’ll help you verify fitment before you buy.
Veteran-owned · Austin, Texas · Mon–Fri 9:30a–11:00a & 1:00p–5:30p CT
Important notes before you order
- Provides 0-2.5" Front Lift
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-359832 |
| Adjustable Damping | Non-Adjustable |
| Body Design | Smooth Body (Non-coilover) |
| Boot Included | No |
| Collapsed Length (IN) | 16.20 |
| Collapsed Length (mm) | 411.5 |
| Extended Length (IN) | 22.13 |
| Extended Length (mm) | 562 |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Crossbar |
| PartType | Shocks / Struts |
| Piston Diameter | 46mm |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 (Ride Height Adjustable) |
| Shaft Diameter | 18mm |
| Spring Seat Included | Yes |
| Stroke/Travel Length (IN) | 5.93 |
| Stroke/Travel Length (mm) | 150.5 |
| Upper Mount Type | Stem |
| Country of Origin | US |
| Warranty | Lifetime |
| Weight (lbs) | 10 |
California Proposition 65 warning applies to this product. www.P65Warnings.ca.gov
Features
- 46mm monotube design ensures consistent fade-free performance in all conditions
- Practical alternative to coil spring spacers with the benefit of Bilstein monotube technology
- Adjustable spring seat offers 0-2.75in of lift depending on the application
Fitment
| Years | Vehicle |
|---|---|
| 2023-2026 | Chevrolet Colorado Trail Boss (Front): Provides 0-2.5" Front Lift |
| 2023-2026 | GMC Canyon AT4 (Front): Provides 0-2.5" Front Lift |
| 2023-2026 | GMC Canyon Denali (Front): Provides 0-2.5" Front Lift |
| 2023-2026 | GMC Canyon Elevation 4WD (Front): Provides 0-2.5" Front Lift |
Use the fit check above with your truck selected, or ask a specialist if your trim isn't listed.
Installation
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting. Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.
Specifications
- Collapsed Length (in): 16.20
- Extended Length (in): 22.13
- Collapsed Length (mm): 23.0
- Extended Length (mm): 562.0
- Stroke/travel Length (in): 5.93
- Lower Mount Type: Crossbar
- Upper Mount Type: Stem
- Internal Design: Monotube
- Finish: Zinc Plated
- Reservoir: No
- Body Design: Smooth Body (Non-coilover)
- Body Diameter (od): 2.0 in.
- Piston Diameter: 46mm
- Boot Included: No
- Spring Seat Included: Yes
- Shaft Diameter: 18mm
- Adjustable Damping: Non-Adjustable
- Country of Origin: US
- Quantity per Vehicle: 2
- UPC: 00651860971506
