Bilstein 24-336222 B8 5100 - Suspension Shock Absorber
Questions about fitment? Live chat or call 866-235-4715
Couldn't load pickup availability
- Free shippingMost orders $500+
- 30-day returnsSee policy
- Warranty supportWe work with the maker
Questions about fitment?
Talk to a TRU specialist
We’ll help you verify fitment before you buy.
Veteran-owned · Austin, Texas · Mon–Fri 9:30a–11:00a & 1:00p–5:30p CT
Important notes before you order
- Fits Vehicles With 0-1.5" Rear Lift
Specifications
| Brand | Bilstein |
|---|---|
| Part number | 24-336222 |
| Adjustable Damping | Non-Adjustable |
| Body Design | Smooth Body (Non-coilover) |
| Boot Included | Black Bellows |
| Collapsed Length (IN) | 16.22 |
| Collapsed Length (mm) | 411.9 |
| Extended Length (IN) | 25.00 |
| Extended Length (mm) | 634.9 |
| Finish | Zinc Plated |
| Internal Design | Monotube |
| Lower Mount Type | Eye 12.1mm |
| PartType | Shocks / Struts |
| Piston Diameter | 46mm |
| Reservoir | No |
| Segment | Light Truck |
| Series | B8 5100 |
| Shaft Diameter | 14mm |
| Spring Seat Included | No |
| Stroke/Travel Length (IN) | 8.78 |
| Stroke/Travel Length (mm) | 223 |
| Upper Mount Type | Eye 12.1mm |
| Country of Origin | US |
| Warranty | Lifetime |
| Weight (lbs) | 5.2 |
California Proposition 65 warning applies to this product. www.P65Warnings.ca.gov
Features
- 46mm monotube design ensures consistent fade-free performance in all conditions
- Patented digressive valving instantly reacts to changing surface conditions
- Vehicle specific tuning
Fitment
| Years | Vehicle |
|---|---|
| 2024-2026 | Ford Ranger Lariat (Rear): Fits Vehicles With 0-1.5" Rear Lift |
| 2024-2026 | Ford Ranger XL (Rear): Fits Vehicles With 0-1.5" Rear Lift |
| 2024-2026 | Ford Ranger XLT (Rear): Fits Vehicles With 0-1.5" Rear Lift |
Use the fit check above with your truck selected, or ask a specialist if your trim isn't listed.
Installation
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
Bilstein B8 5100 shock absorbers are designed as a direct fit solution for lifted trucks and SUV’s. These shock absorbers feature a monotube design which provides consistent fade free performance. B8 5100 shock absorbers utilize a unique, velocity sensitive, digressive piston which reacts to changing road conditions. All B8 5100 shock absorbers are tuned for each specific application to assure optimal performance is achieved. B8 5100 shock absorbers offer a significant improvement in ride quality, handling, and comfort.
Specifications
- Collapsed Length (in): 16.22
- Extended Length (in): 25.00
- Collapsed Length (mm): 21.6
- Extended Length (mm): 634.9
- Stroke/travel Length (in): 8.78
- Lower Mount Type: Eye 12.1mm
- Upper Mount Type: Eye 12.1mm
- Internal Design: Monotube
- Finish: Zinc Plated
- Reservoir: No
- Body Design: Smooth Body (Non-coilover)
- Body Diameter (od): 2.0 in.
- Piston Diameter: 46mm
- Boot Included: Black Bellows
- Spring Seat Included: No
- Shaft Diameter: 14mm
- Adjustable Damping: Non-Adjustable
- Country of Origin: US
- Quantity per Vehicle: 2
- UPC: 00651860963525
