FOX 2.5 IFP Front Coil-Over · 0-3 Inch Lift · Performance Series HTO · 0-3 Inch Lift Ford Bronco (21-25)
- Lift 0-1.5"
- Finish Clear-anodized
- Install 2 hrs
- Difficulty Moderate
Questions about fitment? Live chat or call 866-235-4715
Couldn't load pickup availability
- Free shippingMost orders $500+
- 30-day returnsSee policy
- Warranty supportWe work with the maker
Questions about fitment?
Talk to a TRU specialist
We’ll help you verify fitment before you buy.
Veteran-owned · Austin, Texas · Mon–Fri 9:30a–11:00a & 1:00p–5:30p CT
Specifications
| Brand | FOX |
|---|---|
| Part number | FOX98762000 |
| Lift Height | 0-1.5" |
| Adjustable Damping | No |
| Compressed Length | 17.2 |
| Extended Length | 22.71 |
| Finish | Clear-anodized |
| Gas Charged | Yes |
| Lower Mount Code | Bar Pin |
| Lower Mount Type | Bar Pin |
| Position | Front |
| Shaft Diameter | 5/8" |
| Travel Length | 5.51 |
| Type | Coil-Over |
| Upper Mount Code | OEM |
| Upper Mount Type | OEM |
| Install time | 2 hrs |
| Difficulty | Moderate |
| Required Tools | Strut Compressor |
Features
- 2.5” Impact extruded 6061-T6 aluminum shock body
- Type II clear-anodized body plating
- High-flow velocity-sensitive damping
- 5/8” hard chrome shaft
- Internal floating piston (IFP)
- Hydraulic Top Out (HTO) piston
Installation
- Estimated install time2 hrs
- DifficultyModerate
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
FOX 2.5 Performance Series HTO shock is a bolt-on shock loaded with position-sensitive technology, vehicle-specific valving, and larger pistons to improve on and off-road performance. A type II anodized aluminum body efficiently dissipates heat and prevents corrosion. The 2.5-inch shock body features an internal floating piston (IFP) to separate the shock oil from the high-pressure nitrogen, optimizing damping. The 2.5-inch HTO shocks for the Ford Bronco reuses the existing OE spring.
Hydraulic Top Out (HTO) technology offers usable position-sensitive rebound damping control on and off the pavement. HTO reduces harsh top-outs and increases comfort by forcing shock oil through a secondary shim stack to slow down shock shaft speed; HTO is particularly beneficial after installing heavier, aggressive tires and applications lifted higher than OEM specification.
Bolt-on 2.5 Performance Series HTO shocks to increase damping capacity and ride in comfort with position-sensitive rebound control.
