BDS Suspension

4 Inch Lift Kit | Ram 1500 w/ Air Ride (25-26) 4WD

Name: 4 Inch Lift Kit | Ram 1500 w/ Air Ride (25-26) 4WD
Brand: BDS Suspension
SKU: BDS2122FS
Price: 2689.6 USD
Availability: InStock

4 Inch Lift Kit | Ram 1500 w/ Air Ride (25-26) 4WD

PART #

$2,689.60

SALE Backordered

Shipping calculated at checkout.

Product variants

Quantity

Inventory: Live-Chat or Call

View full details

Important: Always read the entire product description, including Important Notes and Fitment information, before making a purchase. Components contained in images and descriptions may change based upon your selections.

Features

High clearance crossmember design maximizes ground clearance
Robust steering knuckles maintain ESC system compliance
HD skid plate system improved offroad protection
Multipoint differential relocation brackets to secure the front axle and improve CV angles
FOX performance series IFP gas rear shocks to improved ride and offroad performance
Factory Protection Plus drivetrain warranty included

Extreme care/caution must be taken to follow the steps of these instructions to prevent any air leaks or damage to the bags during installation.
The factory air ride is a closed-loop system. Opening the system more times than recommended in the lift instructions will require the system to be recharged (this can be done at any RAM dealer service department). A scan tool is needed to access the air control module to perform the service.
Frame bracket modification is required.
Fits 4WD models equipped with factory air ride only.
Stock 18" wheels cannot be reinstalled due to steering interference. Stock 20"+ wheels can be reinstalled with factory-size tires.
Trucks equipped with factory 22" wheels must use the large bore steering knuckles.
Does NOT fit Diesel Models.
Will NOT fit models equipped with the Thermal Axle option. Reference build code DSK-P or check the diff cover for cooling lines mounted.
IF USING 18IN WHEELS WITH MAXIMUM RECOMMENDED BACKSPACING, TEST FIT WHEELS ON VEHICLE BEFORE MOUNTING TIRES TO ENSURE CLEARANCE
Included Replacement front brake lines (22545) do not work on 2025 model year trucks, relocation bracket is used instead. See instructions for bracket details

Quick Specs

Estimated Installation Time: 10 hrs
Installation Difficulty: Difficult
Special Tools Required: 35mm Axle Nut Socket

Recommended Wheels and Tires

18x9 Wheels and 35x12.5 Tires w/ 4.5in Backspacing
20x9 Wheels and 35x12.5 Tires w/ 5in Backspacing
