ICON Billet Coilover Preload Adjustment Spanner Wrench, 2 Pin
- Finish Anodized
- Material Aluminum
Questions about fitment? Live chat or call 866-235-4715
Couldn't load pickup availability
- Free shippingMost orders $500+
- 30-day returnsSee policy
- Warranty supportWe work with the maker
Questions about fitment?
Talk to a TRU specialist
We’ll help you verify fitment before you buy.
Veteran-owned · Austin, Texas · Mon–Fri 9:30a–11:00a & 1:00p–5:30p CT
Important notes before you order
- Do not adjust preload beyond ICON-specified measurement of exposed threads (refer to shock instructions for recommended measurement)
Specifications
| Brand | ICON Vehicle Dynamics |
|---|---|
| Part number | 198001 |
| UPC / GTIN | 840103408507 |
| Adjustable | No |
| Carrying Case Included | No |
| Color | Black |
| End 1 Angle Head | No |
| End 1 Flex Head | No |
| End 1 Indexable Head | No |
| End 1 Offset Head | No |
| End 1 Ratcheting Type | Non-Ratcheting |
| End 1 Size | .375 IN |
| End 2 Angle Head | Yes |
| End 2 Angle Head Angle | 60 DD |
| End 2 Flex Head | No |
| End 2 Indexable Head | No |
| End 2 Ratcheting Type | Non-Ratcheting |
| End 2 Size | .375 IN |
| End 2 Type | Pin |
| Finish | Anodized |
| Flex Head | No |
| Grade Type | Performance |
| Handle Color | Black |
| Handle Grip | No |
| Handle Grip Color | Black |
| Handle Grip Material | Aluminum |
| Jaw Surface | Smooth |
| Material | Aluminum |
| Maximum Opening | 0.375 IN |
| Minimum Opening | 0.375 IN |
| Universal Or Specific Fit | Specific |
| Country of Origin | US |
| Warranty | TOOL - NO WARRANTY |
California Proposition 65 warning applies to this product. www.P65Warnings.ca.gov
Features
- Features extra 3/8” dowel at end of spanner handle for limited clearance applications
- Includes magnetically-attached 5/32" allen key for collar set screw
- Laser marked measurement guides for precise adjustment of preload
- Magnetic back allows for convenient storage
- Built-in bottle opener for access to a wide range of celebratory beverages
Installation
Free install support from the Trucks R Us tech team, for you or your shop.
Overview
In an effort to provide both enthusiasts and professionals with a tool that will withstand the test of time, ICON developed this spanner wrench that incorporates several unique features to make it a useful addition to any home garage, auto shop, or trail-tailored tool bag.
These features include two 3/8" dowels - one on the end of a hook for convenient leverage against the adjuster nut and one straight for easy access in limited clearance applications. A 5/32" allen wrench is magnetically attached to the back of the handle for quick adjustment of coil adjuster set screw without multiple trips back & forth to the toolbox. ICON engineers even included several handy measurement markings on this tool to allow for on-the-spot measurement of preload, again cutting down time spent on the adjustment process and eliminating the need for a separate measuring device. When preload has been adjusted and the process comes to a close, ICON has your back with a built-in bottle opener that will grant you access to your favorite refreshment while utilizing the magnetic back of this tool for convenient and secure storage on any ferrous surface.
